Description
Technical Specifications
• 12 place settings
• Energy Class: 4 Energy Stars
• Noise level: 48 dB (re 1 pW)
• 5 programmes: Intensive 70 °C, Auto 45-65 °C, Eco 50 °C, Quick wash 45 °C, Pre-Rinse
• Special option: VarioSpeed, HygienePlus
• 4 cleaning temperatures
• ActiveWater hydraulic system
• DosageAssist
• BLDC motor for heat and drain pump
• AquaSensor, Load Sensor
• Detergent Automation
• Alternating spray
• Regenerative electronics
• Self-cleaning filter system with 3-fold corrugated filter
• Stainless steel/Polinox
• Time remaining indicator front
• LED colour on indicators red/red
• Electronic delay timer: 1-24 hours
• LED salt refill indicator
• LED rinse aid refill indicator
• Retractable rotary knob
• VarioFlex basket system
• Silver XXL baskets with pullout handle
• Rackmatic 3-stage
• 2 foldable plate racks in top basket
• 4 foldable plate racks in bottom basket
• Variable cutlery basket in bottom basket
• 2 x cup shelves
• AquaStop – Prevent Water Leakage
• Childproof door lock
• Servo-lock
• Glass care system
• Front-adjustable rear foot
• Inclusive Steam protection plate
• Dimensions of the product (HxWxD): 81.5 x 59.8 x 57.3 cm
Technical Information
General
Width of the product (mm) 598 mm
Height of the product (mm) 815 mm
Installation typology Built-in
Number of place settings 12
Water consumption 9.9 l
Total annual energy consumption 186.6 kWh
List of programmes Auto, Economy, Intensive, Pre-Rinse, Quick wash
Additional operational options VarioSpeed
Digital countdown indicator
Noise level (dB) 48
Interior light
Removable top
Length electrical supply cord (cm) 175 cm
Length outlet hose (cm) 190 cm
Construction type
Control panel shape Bosch initial class
Color / Material body Lacquered
Color / Material panel Stainless steel colour, lacqu.
Construction type Built-in
Door panel options Not possible
Drying system Inherent heat
Height of the product (mm) 815 mm
Hidden heating element
Installation typology Built-in
Removable top
Tub material Plastic
Water softener
Width of the product (mm) 598 mm
Size and weight
Height with worktop (mm) 815 mm
Number of Options 2
Adjustable plinth both horizontal and vertical
Net weight (kg) 52.804 kg
Programmes
List of programmes Auto, Economy, Intensive, Pre-Rinse, Quick wash
Name, programme 1 Intensive
Name, programme 2 Auto
Name, programme 3 Economy
Name, programme 4 Quick Wash
Name, programme 5 Pre Rinse
Programme duration, programme1 (min.) 125-135
Programme duration, programme2 (min.) 95-160
Programme duration, programme3 (min.) 210
Programme duration, programme4 (min.) 29
Programme duration, programme5 (min.) 15
Reference programme Eco
Number of different wash temperatures 4
Temperature, programme 1 (°C) 70
Temperature, programme 2 (°C) 45-65
Temperature, programme 3 (°C) 50
Temperature, programme 4 (°C) 45
Temperature, programme 5 (°C) 0
Safety
Glass protection techn. Yes
Surge-back protect. installed Yes
Water protection system Total system
Consumption values
Glass protection techn.
Total annual energy consumption 186.6 kWh
Energy consumption (kWh) 0.85 kWh
Energy consumption, programme1 (kWh) 1.45-1.5
Energy consumption, programme2 (kWh) 1-1.6
Energy consumption, programme3 (kWh) 0.846
Energy consumption, programme4 (kWh) 0.8
Energy consumption, programme5 (kWh) 0.05
Water consumption, programme 1 (l) 12-15
Water consumption, programme 2 (l) 9-19
Water consumption, programme 3 (l) 9.9
Water consumption, programme 4 (l) 10
Water consumption, programme 5 (l) 4
Water consumption 9.9 l
Maximum temperature for water intake (°C) 60 °C
Connection
Connection rating (W) 2,400 W
Length electrical supply cord (cm) 175 cm
Current (A) 13 A
Length inlet hose (cm) 165 cm
Length outlet hose (cm) 190 cm
Plug type GB plug
